In comparison to traditional electric storage water heater, our low energy consumption DC-Heater can reduce water heating costs up to 40%, thereby conserving energy and emitting low levels of carbon dioxide. The DC-Heater is designed for easy installation anywhere: it is compact and can be mounted on the wall in order to save space. The DC Powered Hot Water System can also be fitted into any existing storage heater household.
- Safe: No heating elements, thus no worry of electrocution.
- Saves cost: Low power consumption 3,000 watts compared to the traditional heaters that use more than 8,000 watts.
- Saves up to 60% of energy.
- Uses patented technology.
- No more hassle of laying the copper piping.
- Easy installation.
Certification
Technology
- 100% consistency hot water supply
- 50% / 50% boiling time
- Faster and energy saving
- Temperature control
- Temperature indicator
- No heating element
- Good insulation
Piping connection
Specification
| Model | CS-100L |
| Capacity | 100 liter |
| Rated voltage | 240V |
| Rated current | 2.75 Apms |
| Rated power | 660 Watt |
| Frequency | 50/60 Hz |
| Rated max. temp. | 60°C |
| Rated max pressure | 10 bar |
| Rated pressure relief valve | 7.5 bar |
| Thermal cut (overheat protection) | 93°C |
| Rated pressure | 0.65 MPa |
| IP code | IP 21 |
| Tank nett weight | 21.1 kg |
| Tank gross weight | 25.1 kg |
| Product size (mm) | W-435
H-410
L-1015 |
| Carton size (mm) | W-435
H-460
L-1120 |
| Inner cylinder tank (stainless steel grade 304) | 1.5mm |
| Tank insulation (Polyurethane rigid injection) | 50mm |
| Heat source module | Ceramic P3 |
| Thermostat control | Automatic |
| Inlet and outlet | BSP 1/2" |
| Installation (horizontal) | Wall mounted |
